CV-305P
3G/HD/SD-SDI scaler to HDMI & audio out
  • SD/HD/3G SDI compliant
  • HDCP 1.1 and DVI 1.0 compliant
  • Scales up and down VESA compliant formats (VGA and DVI)
  • Scales SD/ED/HD video inputs to VESA compliant formats
  • PIP and PAP support
  • Advanced video processing supports: noise reduction, color management, fleshtone control, dynamic contrast control, closed caption support for CVBS, 3D de-interlacing, 3:2/2:2 pull down detection and recovery.
  • Selectable analog stereo and S/PDIF audio support for HDMI audio
  • RS-232 Firmware upgradable to guarantee the functionality revised.
  • Equivalent to 6 different video format switcher to HDMI
  • Video output supports up to WUXGA, UXGA or 1080p
  • Supports stereo audio and S/PDIF
  • Supports 8 channel SDI digital audio
  • Supports two up to 3G-SDI loop-outs
  • HDMI / DVI compliant output
  • Versatile IR control
  • Push button control
總覽

The CV-305P 3G/HD/SD-SDI to HDMI Scaler-Converter offers the highest compatibility among SDI, composite, component, DVI, VGA, HDMI and S-Video to HDMI or DVI in the market. This unique device supports analog and digital conversion and scaling without loss of quality. With the embedded advanced de-interlacer, interlaced video inputs, such as component, composite and S-Video, can be further improved. CV-305P supports the insertion of stereo analog audio and S/PDIF inputs into HDMI output with local duplicated outputs! For SDI, CV-305P can support up to 8 digital audio channel embedded in SDI stream and make perfect conversion between SDI and HDMI signals. With this advanced feature, users can combine asynchronous video and audio sources into the state-of-art HDMI compliant A/V signal for further long range lossless transmission and high standard A/V experience!
CV-305P is especially designed to ease the SDI conversion to the common HDMI interface with affordable cost. With CV-305P, SDI will not become a bottleneck in your applications and the handy audio support can make the input video and audio become HDMI ready. With versatile IR remote control and push buttons, CV-305P offers a very easy way to convert, switch, adjust videos at your convenience. With PIP and PAP support, users can display two video inputs at the same time!

產品規格
Technical
  • HDMI Compliance
  • HDCP Compliance
  • DP compliance
  • USB compliance
  • Max. Data Rate
  • Max. Resolution
  • HDR
  • Latency
  • Audio Support
  • CEC control
  • IR Control
  • IR Frequency
  • EDID Selection
  • RS232 Control
  • ESD protection
  • POC
  • B。SDI Output Formats
  • B。HDMI Input Formats
  • B。SDI Speeds Supported
  • B。Video Sampling
  • B。Audio Sampling
  • B。Auto Switching
  • B。Cable Equalization
  • B。Eye-patten Measurements
  • B。Eye-patten Measurements
  • B。RP-198 pathological patterns
  • C。Cable (Belden 1694A) equalization /ransmission
  • C。Fiber Extension
  • D。Control Interface
  • D。Included Accessories
Mechanical
  • Housing Design
  • Casing Style
  • Power Connection
  • Power Supply
  • Power Consumption
  • Operating Humidity
  • Operation temperature
  • Product Weight
  • Package Weight
  • Certifications
