SP-5002IZM
1x2 HDMI 2.0a Splitter with Built-in& User Adjustable EDID Management
  • Supports 4K2K@60 4:4:4 8bits
  • Supports HDR1, which is 4K2K@60 4:2:0 10bits2
  • HDCP 2.2 and 1.4 compliant
  • Wide frequency range: 25MHz~600MHz
  • Video bandwidth: 18Gbps
  • Supports resolution downscaling from 4K2K to 1080P!
  • Supports default EDID and EDID learning from display
  • Supports xvYCC, x.v.Color& Deep Color
  • Micro-USB firmware update for expanding compatibility
  • Supports Dolby Digital, DTS-HD and Dolby TrueHD audio
總覽

The SP-5002IZM 1x2 HDMI 2.0a Splitter with Built-in& User Adjustable EDID Management provides the most cost effective and advanced HDMI splitter solution in the market, by which the high definition video and high quality audio can be transmitted to 2 different locations without losing any quality.SP-5002IZM also supports HDR and the true 4K2K video!

With built-in USB firmware update mechanism, the compatibility among countless HDMI sources and receivers can be further guaranteed. With the upmost HDR/4K2K@60 4:4:4 8bits and high definition audio support, SP-5002IZM is suitable for high quality HDMI broadcasting, digital signage and education applications!

產品規格
Technical
  • HDMI Compliance
  • 2.0

  • HDCP Compliance
  • 2.2/1.4

  • Max. Data Rate
  • 18 Gbps

  • Max. Resolution
  • 4K2K@60 (4:2:0—10bits)
    4K2K@60 (4:4:4—8bits)

  • HDR
  • 4:2:0|4:2:2|4:4:4—10 or 12bits
    HDR10; HDR10+; Dolby Vision; HLG

  • Audio Support
  • Dolby TrueHD, DTS-HD Master Audio, Dolby Digital Plus, LPCM 7.1 Audio

  • CEC control
  • Pass through

  • EDID Selection
  • 4 options

  • ESD protection
  • 8 KV—Contact Discharge
    15KV—Air Discharge

Mechanical
  • Housing Design
  • Metal

  • Casing Style
  • Wall Mountable

  • Power Connection
  • Interlocking Barrel

  • Power Supply
  • 5V DC, 1A

  • Power Consumption
  • 3 watts (Max.)

  • Operating Humidity
  • 20-90% RH (no condensation)

  • Operation temperature
  • 0~40°C (32~104°F)

  • Product Weight
  • 124g (0.2 lbs)

  • Package Weight
  • 169g (0.3 lbs)

  • Certifications
  • 169g (0.3 lbs)
