    MA-5544O1
    HDMI 2.1 4X4 O1Stream Matrix
    • Supports HDMI 2.1 & HDCP 2.3
    • Supports resolution up to 4K@120 4:4:4
    • Supports USB-C (Alt Mode DP 1.4)
    • Supports VRR(Variable Refresh Rate) & ALLM(Auto Low Latency Mode)
    • Extends the transmission over cat.5e cable up to 100m (330ft) from the HDMI source at Ultra-HD 4K@120 4:4:4
    • Supports Multi-Encode & Decode capability (proprietary codecs)
    • Latency: <
    • 1 frame
    • HDCP & CEC Bypass
    • Supports EDID management
    • Supports audio extraction and embedding via TOSLINK
    • Supports Bi-directional S/PDIF audio path-through
    • Pure unaltered uncompressed 7.1ch digital HDMI over cat.5e transmission
    • DTS-HD Master Audio and Dolby TrueHD high bit rate audio support
    • Supports bi-directional full frequency IR signal from 20KHz to 60KHz
    • Supports eARC/ARC
    • Allows any source to be displayed on multiple displays at the same time
    • Allows any HDMI display to view any HDMI source at any time
    • Supports software to configure & upgrade device and to control the switching operation of the various signal types
    • The matrix switcher can switch every output channels from any HDMI inputs by Push button, IR remote control, web-interface control
    • Supports device cascading
    Overview
    The MA-5544O1 HDMI 2.1 4X4 O1Stream Matrix is the most flexible and cost-effective solution available in the market for routing high-definition video sources and high-quality audio from any of the four HDMI sources to remote displays simultaneously. By using a single, cost-effective Cat.X cable, it is possible to extend HDTV sources from HDMI-enabled devices, such as set-top boxes, PlayStation, Xbox, PC, and laptops, to remote display monitors, including HDMI-enabled TVs and LCD PC monitors.
    MA-5544O1 supports transmission distances of up to 100 meters (330 feet) over standard copper cabling, delivering Ultra HD 4K@120Hz 4:4:4 performance. It also supports daisy-chain connections via fiber optic cables, allowing multiple units to be linked together for extended distribution.
    In addition, the MA-5544O1 features bi-directional IR pass-through, USB 3.1 and audio extraction & embedding, providing flexible control and connectivity options. Designed for reliability and performance, the MA-5544O1 is ideal for professional AV installations, including high-quality HDMI broadcasting, digital signage, and education environments.
    SPECIFICATIONS
    Technical
    • HDMI Compliance

    • 2.1

    • HDCP Compliance

    • 2.3

    • Video Bandwidth

    • up to FRL 6 (48G)

    • Video Support

    • up to 4K@120 4:4:4

    • HDMI over UTP

    • 100m (330ft) from the HDMI source at Ultra-HD 4K@120 4:4:4

    • Console Management

    • USB-A (WebGUI)

    • IR Control

    • Two Way

    Mechanical
    • Housing Design

    • Metal

    • Casing Style

    • 1U Rack Mountable

    • Power Connection

    • Interlocking Barrel

    • Power Supply

    • 12V DC

    • Power Consumption

    • 36 watts (Max.)

    • Operating Humidity

    • 20-90% RH (no condensation)

    • Operation temperature

    • 0~40°C (32~104°F)

    • Product Weight

    • Dimensions：440 (L) x 44 (H) x 201 (D)mm
      Weight：1.5kg

    • Package Weight

    • CE, FCC, RoHS

    • Certifications
