    4-Port DisplayPort 1.4/Audio MST KVM Switch with USB 3.1 Gen 1 HUB
    • DP 1.2 compliant
    • Supports 4K2K@60 4:4:4 8bits, Video bandwidth 18Gbps
    • Supports 4K2K@60 4:4:4 8bits
    • Supports separate line input and output
    • Supports built-in 4-port USB 3.0 HUB to share USB devices
    • Supports hotkeys function
    • Supports default HDMI EDID and learns the EDID from displays
    • Firmware upgradable
    Overview
    The PS-4004U3A-MST 4-Port DisplayPort 1.4/Audio MST KVM Switch with USB 3.1 Gen 1 HUB provides the most flexible and cost effective solution in the market for multiple computer management at home & office. With built-in MST(Multi-Stream Transport) hub, users can adopt two console displays from a single DisplayPort enabled laptop or PC, and extend the laptop or PC to additional displays and stream independent content to each individual display to make multitasking easier and increase your productivity. The KVM switch can control 4 DisplayPort USB computers by one set of console peripherals (keyboard, mouse & monitor). With built-in USB 3.1 Gen 1 hub, users can share USB peripheral devices between connected computers.
    SPECIFICATIONS
    Technical
    • Video﹁

    • DisplayPort

    • 4Kx2K @60Hz, HDCP 1.3

    • Bandwidth

    • 21.6Gbps

    • Resolution

    • #1 display: up to 7680x4320@30 #2 displays: up to 3840x2160@60

    • USB 3.1 Gen 1

    • 4x Type-A & 1x Type-B, up to 5Gbps

    • USB 1.1

    • 2x Type-A, up to 12Mbps

    • Audio﹁

    • 7.1 channel surround sound

    • PCM 2.0 channel stereo digital audio

    • OS Compatibility

    • Windows®, macOS®

    Mechanical
    • Housing Design

    • Metal

    • Casing Style

    • Standalone

    • Power Connection

    • Interlocking Barrel

    • Power Supply

    • 12V DC, 2A

    • Power Consumption

    • 10 watts (Max.)

    • Operating Humidity

    • 20-90% RH (no condensation)

    • Operation temperature

    • 0~40°C (32~104°F)

    • Product Weight

    • Dimensions：7.95” (L) x 1.46” (H) x 4.42” (W)
      Weight：1.53 lbs

    • Package Weight

    • Dimensions：13.03" (W) x 8.03" (H) x 6.37" (D)
      Weight: 4.11 lbs

    • Certifications

    • CE, FCC, RoHS
