- 12G/6G/3G/HD/SD-SDI distribution
- Eight separately buffered and reclocked outputs*
- Cable equalization and signal retiming
- LED indication of signal lock and video rate
- Passes ancillary data and embedded audio
- Provides automatic input cable equalization (Belden 1694A) up to 180m (594ft)@3G, 100m (330ft)@6G and 70m(230ft) @12G
- Reclocking SDI signals for cascading and thus longer transmission
- Inter-locked power supply for better fixedness
The SP-3008KG 1x8 12G/6G/3G/HD/SD-SDI Distribution Amplifier with Reclocking receives one SDI input, perfectly duplicates it, and re-transmits eight SDI outputs for real time multi-viewing. It is a reliable video device splitting a SDI, HD-SDI, 3G-SDI, 6G-SDI, or 12G-SDI video source to eight SDI compliant displays at the same time.
-
HDMI Compliance
-
2.0
-
SDI Formats
-
SMPTE 2082; 11.88 Gbps／12G-SDI：2160p at 50/59.95/60 Hz。
SMPTE 2081; 5.94 Gbps／6G-SDI：2160p at 25/29.97/30 Hz。
SMPTE 424M; 2.97 Gbps／3G-SDI 1080p at 50/59.94/60 Hz (4:2:2)。
SMPTE 274M; 1.485 Gbps／HD-SDI：1080p at 23.98/24/25/29.97/30 Hz, 1080i at 50/59.94/60 Hz。
SMPTE 296M; 1.485 Gbps／HD-SDI：720p at 23.98/24/25/29.97/30/50/59.94/60 Hz。
SMPTE 292M; 1.485 Gbps／HD-SDI：1080i at 30 Hz, 720p at 60 Hz。
SMPTE 259M; 270 Mbps／SD-SDI：NTSC 525 at 59.94 Hz, PAL 625 at 50 Hz。
-
HDMI Formats
-
4K UHD Video Standards／2160p at 23.98/24/25/29.97/30/50/59.94/60 Hz
UHD Video Standards／1080p at 50/59.94/60 Hz (4:2:2)
HD Video Standards／720p at 50/59.94/60 Hz, 1080i at 50/59.94/60 Hz, 1080p at 23.98/24/25/29.97/30 Hz
SD Video Standards／NTSC at 59.94 Hz, PAL at 50 Hz
-
SDI Bitrate
-
270 Mbps, 1.485 Gbps, 2.97 Gbps, 5.94 Gbps, 11.88 Gbps
-
Video Sampling
-
4：2：2
-
Audio Sampling
-
48 kHz & 24 bit
-
Auto Switching
-
Auto switching between SD／HD／3G／6G／12G-SDI
-
Cable Reach
-
[12G-SDI] up to 60m (200ft)
[6G-SDI] up to 75m (250)
[3G-SDI] up to 90m (300ft)
[HD-SDI] up to 150m (500ft)
[SD-SDI] up to 300m (1000ft)
-
Eye-patten Measurements
-
Amplitude：within 800mV
Raise&Fall time：<45ps> Timing jitter：<8> Alignment jitter：<0.3(100KHz to 1188MHz)
-
ESD Protection
-
8 KV—Contact Discharge
15KV—Air Discharge
-
Housing Design
-
Metal
-
Casing Style
-
Wall Mountable
-
Power Connection
-
Interlocking Barrel
-
Power Supply
-
5V DC, 1A
-
Power Consumption
-
3.5 watts (Max.)
-
Operating Humidity
-
20-90% RH (no condensation)
-
Operation temperature
-
0~40°C (32~104°F)
-
Product Weight
-
198g (0.4 lb.)
-
Package Weight
-
425g (0.9 lb.)
-
Certifications
-
CE, FCC, RoHS
