SP-5002PU
1x2 HDMI 2.0(YUV 4:2:0) 4K2K Splitter with Built-in & User Adjustable EDID Management
  • Supports HDMI Deep Color & 3D / DVI 1.0 compliant
  • HDCP 1.3 compliant
  • Wide frequency range: 25MHz~340MHz
  • Video bandwidth: 10.2Gbps
  • Resolution up to 4K2K @30
  • Supports default EDID and has ability to learn the EDID of displays
  • Supports xvYCC, x.v.Color & Deep Color
  • Mini-USB firmware update for expanding compatibility
  • Supports Dolby Digital, DTS-HD and Dolby TrueHD audio
  • Easy installation
總覽

The SP-5002PU 1x2 HDMI 2.0(YUV 4:2:0) 4K2K Splitter with Built-in & User Adjustable EDID Management provides the most cost effective and advanced HDMI splitter solution on the market, by which the high definition video and high quality audio can be transmitted to 2 different locations without losing quality. SP-5002PU supports all 3D formats and the true 4K2K video!

With built-in RS-232 firmware update mechanism, the compatibility among countless HDMI sources and receivers can be further guaranteed. With the upmost 36 bit deep color video and high definition audio support, SP-5002PU is suitable for high quality HDMI broadcasting, digital signage and education applications!

產品規格
Technical
  • HDMI Compliance
  • 1.4

  • HDCP Compliance
  • 1.3

  • Max. Data Rate
  • 10.2 Gbps

  • Max. Resolution
  • 4K2K@30 (4:2:2—12bits)
    4K2K@30 (4:4:4—8bits)

  • Audio Support
  • Dolby TrueHD, DTS-HD Master Audio, Dolby Digital Plus, LPCM 7.1 Audio

  • CEC control
  • Pass through

  • EDID Selection
  • 7 options

  • ESD protection
  • 8 KV—Contact Discharge
    15KV—Air Discharge

Mechanical
  • Housing Design
  • Metal

  • Casing Style
  • Wall Mountable

  • Power Connection
  • Interlocking Barrel

  • Power Supply
  • 5V DC, 2A

  • Power Consumption
  • 10 watts (Max.)

  • Operating Humidity
  • 20-90% RH (no condensation)

  • Operation temperature
  • 0~40°C (32~104°F)

  • Product Weight
  • 463g (1.0 lbs)

  • Package Weight
  • 946g (2.1 lbs)

  • Certifications
  • CE, FCC, RoHS
